Clothing, food and housing are major issues in people's lives. With the rapid development of the economy, the construction of ecological civilization has become extremely important. Creative container houses are becoming more and more popular due to their advantages of being movable, easy to store, energy-saving and environmentally friendly, superior in earthquake resistance and reusable. They are truly "green buildings". The "Opinions of the CPC Central Committee and the State Council on Further Strengthening Urban Planning and Construction Management" proposed that within about 10 years, the proportion of prefabricated buildings in new buildings should reach 30%, and the development of steel structure buildings should be actively and steadily promoted.
Container houses are green and environmentally friendly, time-saving and labor-saving, flexible and changeable. Compared with traditional housing, they can provide people with more choices. Individuals, families, and even a company can take what they need. A house made of a steel box can also be full of artistic atmosphere, while being environmentally friendly and time-saving.
As the Fangcang Hospital in the fight against the epidemic has proved to the world the practicality of container houses and China's construction speed, people are beginning to pay more attention to the practical performance of creative container houses.
BOXER container house will take you to learn about it!
1. Wall panels
The wall panels made of thermal insulation materials are used to prevent deformation and rust caused by overheating and overcooling. The surface is electrostatically sprayed with graphene powder, the surface is smooth and will not fade for 20 years. In order to ensure bright color and prevent rust, high-end container houses are generally repainted every 3-5 years.
2. Technology
The main frame of the product adopts special cold-bent galvanized steel components, and the enclosure insulation materials are all non-combustible materials. Water, electricity, heating, decoration and supporting functions are all prefabricated in the factory.
3. Connection details
The roof frame, floor, wall and foundation are connected by professional accessories to improve stability and windproof performance.
4. Fire protection
The use of non-combustible materials improves fire resistance, meets relevant design standards, and ensures living...
5. Sound insulation
Meet the building sound insulation standards, use asbestos wall panels to reduce the noise level acceptable to human sleep.
6. Ventilation
Container houses are naturally ventilated, with windows installed, and walls and roofs also have one-way air permeable layers.
7. Resource optimization
Container houses are called new "green buildings" because of their prefabrication, flexibility, energy saving and environmental protection.
Container houses can be recycled, disassembled and assembled without loss, no construction waste, and easy to install.
Detailed parameters of container houses
1. It is a comprehensive parameter.
Dimensions (mm): External dimensions (length * width * height) 6055mm * 2990mm * 2896mm;
Roof form: small slope roof, internal drainage organization.
Number of stacking layers: ≤3 layers
Design life: 20 years.
Ground live load: 2.0KN/㎡
Roof live load: 1.0KN/㎡
Wind load: 0.6KN/㎡
Seismic fortification intensity: 8 degrees
2. It is an overall structure.
Corner: galvanized cold-formed steel, material Q235B,
Main roof beam: galvanized cold-formed steel, material Q235B,
Secondary roof beam: galvanized cold-formed C-shaped steel, material Q235B,
Ground column beam: galvanized cold-formed steel, material Q235B,
Secondary ground beam: galvanized cold-formed C-shaped steel, material Q235B,
Anti-corrosion treatment: electrostatic spraying, outdoor special paint, baking paint process
3. It is the roof structure.
Roof cover: 0.5mm thick galvanized color steel plate; roof panel overlap 360° bite
Insulation layer: single-sided aluminum foil 75mm thick glass wool + PE film, flame retardant performance is A-level,
Ceiling board: stone plastic board
4. It is the ground structure
Decorative surface layer: 1.8mm thick, PVC environmentally friendly plastic floor, light gray;
Structural floor: 18mm thick, cement fiber board, fireproof grade A1;
Insulation layer: single-sided aluminum foil 75mm thick glass wool, flame retardant performance is A-level;
Bottom board: 0.35mm thick color steel corrugated board, white gray color;
5. It is the wall material
Type: (color steel glass wool sandwich board), flame retardant performance is A-level; creative container house can be decorated inside
Texture: (orange peel texture outside and flat plate inside),
Total thickness: 75mm, color steel plate thickness (mm) 0.5mm, the thickness of the creative container is adjusted on this basis.
Effective width: (mm) 1150, height (mm) 2540,
Sandwich material: (A1 grade fireproof glass wool board), sandwich density (kg/m3) 64; the insulation material used in the cultural and tourism container house is better and thicker.
Color: milky white (default), customizable color
6. Door
Entrance door: 840*2035mm steel anti-theft door (ordinary model, special model), according to the terrain structure and aesthetic needs of the cultural and tourism scenic area, the door of the container house can also be designed into different sizes.
In summary, container houses, as a new type of building with a small footprint and easy disassembly, are more in line with the new low-carbon and environmentally friendly lifestyle of the contemporary era by using some energy-saving and environmentally friendly means. The application of creative container houses in cultural and tourism scenic spots and temporary commercial streets will become more and more extensive.
